Water stabilization Q345B steel prefabrication design high -ended arched steel structure bridge

No.11
An arch bridge is usually defined as a vertically curved and axially compressed structural member spanning an opening and providing support for the moving loads above the opening. The deck can be supported or hung from this main structure, and depending on the position of the arch relative to the deck, arch bridges can be classified as deck arch, through arch, and half-through arch bridges
  • Water stabilization Q345B steel prefabrication design high -ended arched steel structure bridge
  • Water stabilization Q345B steel prefabrication design high -ended arched steel structure bridge
  • Water stabilization Q345B steel prefabrication design high -ended arched steel structure bridge
  • Water stabilization Q345B steel prefabrication design high -ended arched steel structure bridge

Description

Product Description
  Steel bridge is a bridge whose main bearing structure is steel, also named steel structure bridge . Fabricated steel bridges have been widely used all over the world. The original fabricated steel bridge was designed by British engineer Donald Bailey at the beginning of World War II in 1938. The main design concept is to assemble the fabricated steel bridge with the least kinds of unit components to carry various loads , which only needs to be transported by general medium-sized trucks, and can be built by manpower under special circumstances.But now,it can be designed freely according to the needs,the length can reach more than ten meters while the weight is several tons or more for one component .And advanced machinery played an important role in the construction.With the development of technology,overhead bridge,metro,overpass and so on are very convenient for us,which is changing our lives a great deal.



Product Prefab Steel Structure Bridge
Material Mild Steel; Stainless Steel
Coating Spray Painting; Galvanization;Powder Coated
Color Blue; Green; Darkgray; Client's Request
Steel code Q235-B; Q345-B; Stainless steel
Fabrication Advanced Automatic Welding Machines
Quality control GB/T19001-2000----ISO9001:2000
Advantages 1. Stable and Aesthetic
2. Structure is durable for 50years
3. Fast and easy to install
4. Extensive Applications: Storage, Warehouse, Exhibition Hall,Terminal Building, Stadium, Theater, Special-shaped Buildings, etc
5. High anti-rust performance
6. Flexible composition: Doors and Day-lighting roof could be  installed at any position





The Features

  1. The seismic performance and wind resistance are good.It can absorb a large amount of energy through deformation to prevent the bridge from collapsing in the earthquake.

  2. The construction is like "building blocks". The speed is fast, and the construction period is short.

  3. The construction is basically not affected by the weather. Even in bad weather, the components can be fabricated in factory,then transported to the construction site for installation.

  4. Large-span construction can be carried out, with a wide range of applications and good applicability.

  5.It’s easy to assemble and disassemble. The components are mainly connected by bolts, If you need to remove it , just remove the bolts directly, and all the steel can be reused in other buildings.

  6.The steel recovered from the bridge can be refurbished, effectively saving steel resources.




The Application

  1.Overhead Bridge

  2.Overpass

  3.Metro

  4.Landscape bridge

  5.Other functions bridge as request




Process Description


 1.Design process:

  (1)As a public building,safety is the most important.So,the materials to be used must be good waterproof and fireproof.

  (2)The wind load,snow load,the degree of earthquake(the maxinium in the past 50 years in noraml )should be considered when design.Ensure the safety of the shopping mall from the design source!

  (3)For such steel building, beautiful appearance is requested.Thus,it should be considered when design.

  (4)More than 100 senior engineers will provide professional support by PKPM,Tekla,3D3S,Auto CAD,SketchUp etc.

  2.Production process

  For such steel structure,high accuracy is damanded.All-round factory quality control of materials, processing, and welding must be carried out to ensure the quality of the components.

  The most skilled workers will participate in the full manufacture ,on the other hand,the advanced equipments contribute to it.

  3.Installation process

  The construction can be accomplished by us or by yourself.If us,Professional engineer and skilled workers will go to the site.Otherwise,video and pictures will be sent for reference.
